Fieseler Fi156C Storch 2850mm (112.2") Wingspan from Black Horse - Balsa Wood ARF - BHFS000
The Fieseler Fi 156 Storch (Stork) was a German liaison aircraft built by Fieseler before and during World War II. Production continued in other countries into the 1950s for the private market. It remains famous for its excellent STOL performance and low stall speed of 31 mph (50 kmph). French-built later variants are often seen at air shows today.
The model is scaled to approximately 1:5 and attention was paid to a true to original appearance and best flight characteristics. The model can be operated using an electric power system or with an internal combustion engine about 30-35cc displacement.
Visit the Official Black Horse Fieseler Fi156C Storch 2850mm Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
Features:
- High level of prefabrication right out of the box
- Lightweight, strong, laser cut balsa and plywood construction
- Panel lines and details printed directly onto the pre-applied, high quality covering
- Aerofoiled tail surfaces
- Recessed hinges on all control surfaces
- Pre-drilled hinge mounting holes
- Heavy-duty pin hinges on all control surfaces
- Large easy access fuel tank/battery/servo access hatches with sprung loaded latches
- Painted and detailed cockpit, pilot and interior included
- Fiberglass control horns with ball link connector
- comprehensive control and fitting accessories included
- Two-piece, plug-in wings simplify transportation and assembly
- Fiberglass cowl and glass reinforced landing gear covers/pants
- Mounts for both electric and gas power options included
- Fully illustrated instruction manual included and available for download (see tab above)
Includes:
- Black Horse Fieseler Fi156C Storch 2850mm (112.2") Wingspan - ARF
Requires (Electric):
- 6 Channel radio - select a minimum 6 channel radio from our Radio Collection
- 6 Channel receiver - select a minimum 6 channel receiver from our Receiver Collection
- 2300-3300 Watt Brushless Outrunner Motor - we recommend the Admiral GP26 6330-245Kv Brushless Motor
- 85-120 Amp Brushless ESC - we recommend Castle Creations Phoenix Edge High Voltage 80A ESC
- 8-18 Amp UBEC - we recommend ZTW 18A BEC / UBEC
- 7x 45g standard servos - we recommend HS-625MG
- For 10S setup TWO 5 Cell 18.5V 5000 - 60000 mAh LiPo Batteries with EC5 connector - we recommend Admiral Pro 6000mAh 5S 18.5V 50C LiPo Battery with EC5 Connector Multi-Pack (2 Batteries)
- 2 to 1 EC5 series adapter - we recommend Admiral EC5 2 to 1 Series Adapter
- Electric propeller - we recommend APC 18x10 Thin Electric Propeller
- 6 Cell compatible battery charger - select a minimum 6 cell (6S) charger from our Charger Collection
Requires (Gas):
- Engine: 35cc 2-stroke (NGH GT35 recommended). 38-42cc 4-stroke (NGH GF38 recommended)
- Gas Propeller: 18x10 - 20x8 (2 Stroke and 4 Stroke)
Black Horse ARF models are constructed out of balsa wood and plywood. These are not foam models. The assembly of balsa wood ARF aircraft requires basic model building skills including the installation of servos, ESC, and motor (or gas engine).
Product Specifications:
Model Scale |
1/5 Scale |
Wingspan |
2850mm / 112.2in |
Length |
1910mm / 75.20in |
Weight |
8100g / 17.82lbs |
CG (Center of Gravity) |
110-120mm from the leading edge of the wing slats |
Power System |
2500 Watt+ Brushless Outrunner Motor or 35cc 2 or 38 - 42cc 4-stroke (required) |
Electronic Speed Control |
60 - 100A (required) |
Propeller / EDF |
18x10 (required) |
Servos |
|
Landing Gear |
Fixed |
Required Battery |
TWO 5S 18.5V 5000mAh LiPos (required) |
Required Radio |
6 Channel (required) |
Ailerons |
Yes |
Elevator |
Yes |
Rudder |
Yes |
Flaps |
Yes |
Lights |
Optional |
Hinge Type |
Nylon Heavy Duty pin hinges |
Material |
Balsa and plywood |
Skill Level |
Intermediate |
Build Time |
6+ Hours |
Recommended Environment |
Outdoors |
Videos
Product Videos
Spare Parts
Product Spare Parts
Hitec HS-625MG Ball Bearing Metal Gear Standard Servo Airplane Multi-Pack (7 Servos)
SKU: HRC6005-001
$21700
Admiral Pro 5000mAh 4S 14.8V 60C LiPo Battery with EC5 Connector Multi-Pack (2 Batteries)
SKU: ADM6024-001
$14749
1 - 29 of 29 results
Upgrades
Product Upgrades
RunCam 6 Action Camera 4K/30FPS with Lens Protection, ND Filter, and SD Card
SKU: RC-RUNCAM6-4K-ND128G
$12499
1 - 5 of 5 results
Q&A
Product questions & answers
NOTE: Questions submitted on this page are answered by customers who have previously purchased this item. If you have a support related question that requires immediate assistance, please visit our Help Center
Support
Product support
Product Manuals:
If you need any additional assistance, please visit the Motion RC Help Center
Hitec HS-625MG Ball Bearing Metal Gear Standard Servo Airplane Multi-Pack (7 Servos)
SKU: HRC6005-001
VIEW PRODUCT
Customer Reviews
- Reviews
Black Horse - Fieseler Storch
By far one of the best kits I have ever purchased; worth every penny. The build is outstanding; the product description on the website does not even begin to talk...read more
Blackhorse Storch
I'm a repet offender with Blackhorse planes and I must say with 7 planes in my hanger my biggest problem is which one do I fly today. Very happy customer
new version is a great flyer!
Excellent! I just wanted to say that the Motion RC Support Team was a pleasure to work with! I had a issue with a wing and they took care of...read more
Blackhorse 112inch Fieseler Storch
The ARF Kit had no surprises thus pretty straight forward assembly. You must search for contact points and cut outs from underneath the covering by feel as the pre-printed vinyl...read more
Fiesler Storch
Loved everthing about it but the tailwheel. Not to scale. Rest of it was great. You folks do good work.
Black Horse Fieseler
Big plane and very good price
-
