Dornier DO335 1724mm (67.8") Wingspan from Black Horse - Balsa Wood ARF - BHM1004-001
The Dornier Do 335 Pfeil ("Arrow") was a German World War II heavy fighter built by the Dornier company. The two-seater trainer version was called Ameisenbär ("anteater"). The Pfeil's performance was much better than other twin-engine designs due to its unique push-pull configuration and the lower aerodynamic drag of the in-line alignment of the two engines. It was Nazi Germany's fastest piston-engined aircraft of World War II.
The model is scaled to approximately 1/8 and attention was paid to a true to original appearance and best flight characteristics. The model can also be operated using an electric power system.
Visit the Official Black Horse Dornier DO335 1724mm Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
 |
Factory Weathered Printing The printing on this model has a realistic weathering complete with rivet and panel line detail that elevates the model to a whole new level of scale appeal. |
 |
Fiberglass Molded Cowl Single piece cowl is molded from fiberglass for the ultimate in rigidity. |
 |
Electric Power This model is meant for electric power. |
 |
Large Electronics Hatch A generously sized battery hatch allows easy access to internal electronics system. |
Features:
- All-new realistic multi-layer weathered printing
- High level of prefabrication right out of the box
- Lightweight, strong, laser cut balsa and plywood construction
- CNC suspension metal struts
- Panel lines and details printed directly onto the pre-applied, high quality covering
- Airfoiled tail surfaces
- Recessed hinges on all control surfaces
- Pre-cut hinge slots
- Heavy-duty CA hinges on all control surfaces
- Large easy access fuel tank/battery/servo access hatches with sprung loaded latches
- Painted and detailed cockpit, pilot and interior included
- Fiberglass control horns
- comprehensive control and fitting accessories included
- Two-piece, plug-in wings simplify transportation and assembly
- Fiberglass cowls
Includes:
- Black Horse Dornier DO335 1724mm (67.8") Wingspan - ARF
Requires:
- 6 Channel radio - select a minimum 6 channel radio from our Radio Collection
- 6 Channel receiver - select a minimum 6 channel receiver from our Receiver Collection
- TWO brushless outrunner motors - we recommend TWO Admiral GP10 5030-400Kv Brushless Motors
- TWO 65 Amp Brushless ESCs - we recommend ZTW Mantis G2 65A ESC with 8A SBEC Multi-Pack (2 ESCs)
- 7x servos - we recommend 7 Hitec HS-645MG Ultra Torque Ball Bearing Metal Gear Standard Servos
- 6 Cell 22.2V 5000 - 6000mAh LiPo Battery with EC5 connector - we recommend the Admiral 5000mAh 6S 22.2V 50C LiPo Battery with EC5 Connector
- Electric propeller - TWO APC 14x8.5 Thin Electric Propellers
- Electronic retracts - we recommend Xwave RM400-90 Electronic Retract Multi-Pack (3 Retracts)
- 6 Cell compatible battery charger - select a minimum 6 cell (6S) charger from our Charger Collection
Black Horse ARF models are constructed out of balsa wood and plywood. These are not foam models. The assembly of balsa wood ARF aircraft requires basic model building skills including the installation of servos, ESC, and motor (or gas engine).
Product Specifications:
Model Scale |
1:8 Scale |
Wingspan |
1724mm / 67.8in |
Length |
1731mm /68.1in |
Weight |
5987g / 13.2lbs |
CG (Center of Gravity) |
175mm from the leading edge of the wing at the root |
Wing Area |
61.4 dm2 |
Wing Loading |
97.72g/dm2 |
Power System |
2x Brushless 400Kv Outrunner Motors (required) |
Electronic Speed Control |
2x 65A (required for electric) |
Propeller / EDF |
2x 14x8.5 propeller (required) |
Servos |
7x 45g standard (required) - we recommend HRC32645S |
Landing Gear |
Electric retract gear size: (92.2 x 51 x 30.6)mm (not included) |
Required Battery |
6 Cell 22.2V 5000 - 6000mAh LiPo Battery with EC5 connector (required) |
Required Radio |
7+ Channel (required) |
Ailerons |
Yes |
Elevator |
Yes |
Rudder |
Yes |
Flaps |
Yes |
Lights |
Optional |
Hinge Type |
Heavy-duty CA |
Material |
Balsa and plywood |
Skill Level |
Intermediate |
Build Time |
6+ Hours |
Recommended Environment |
Outdoors |
