Douglas C-47 1800mm (70.8") Wingspan - ARF from Nexa - NXA1012-001
The Douglas C-47 Skytrain or Dakota (RAF, RAAF, RCAF, RNZAF, and SAAF designation) is a military transport aircraft developed from the civilian Douglas DC-3 airliner. It was used extensively by the Allies during World War II and remained in front-line service with various military operators for many years.
The Nexa Douglas C-47 is a 70" wingspan electric scale series warbird, constructed primarily from balsa wood and covered with a fuel-resistant covering. This ARF requires assembly and installation of your choice of servos and power system, and includes painted pilot, antenna and other scale details. The large battery hatch affords ample room for either electric or gas setups. Impress at your flying field with this iconic stunner!
Please Note: Struts pictured are optional shock absorbing struts. More basic wire struts are included with the plane. The optional struts are located in our "upgrade" or "spare parts" tabs (coming soon).
Visit the Official Nexa Douglas C-47 1800mm ARF Discussion Thread on HobbySquawk.com for additional photos, videos, reviews, and customer Q&A.
 |
Fully Covered and Detailed The Nexa Douglas C-47 comes fully covered including simulated panel lines, rivets, nomenclature and weathering detail. |
 |
Scale Details Throughout There is no shortage of scale details with this C-47 including split flaps, and painted pilot. |
 |
Prehinged and Installed Control Surfaces All control surfaces come out of the box fully prehinged and installed for your convenience. |
 |
Impressive Size Yet Easy To Transport To add to the array of scale detail, the Nexa C-47 comes with a 70" wingspan but the wings are easy to remove for transport. |
Features:
- Complete Balsa and lite-ply construction for rigidity and durability
- Covered from tip to tail in scale details including weathering, printed simulated panel lines and rivets
- Fiberglass cowlings for strength and durability
- The hand-painted pilot is ready for your added cockpit details
- All control surfaces come out of the box pre-hinged and installed for convenience
- Large battery hatch allows for your chosen electric or gas setup
Includes:
- Nexa Douglas C-47 1800mm (70.8") Wingspan - ARF
- Wheels and struts
- Hardware and servo trays
Requires:
- 6 Channel radio - select a minimum 6 channel radio from our Radio Collection
- 6 Channel receiver - select a minimum 6 channel receiver from our Receiver Collection
- 2x Brushless outrunner motors - we recommend the Admiral GP2 3520-950Kv Brushless Motor Multi-Pack (2 Motors)
- 2x 45 Amp brushless ESC - we recommend the ZTW Mantis G2 45A ESC with 4A SBEC Multi-Pack (2 ESCs)
- 4x standard servos for ailerons, elevator and rudder - we recommend the Hitec HS-85BB High Torque Micro Servo Airplane Multi-Pack (4 Servos)
- 4x standard 9g servos for flaps - we recommend FOUR of the Hitec HS-55 9g Micro Servo
- Electric retracts for the landing gear - we recommend Nexa Electronic Retract Set with Struts - Type C
- TWO 3 Cell 11.1V 5000 mAh LiPo Batteries - we recommend TWO of the Admiral 5000mAh 3S 11.1V 50C LiPo Battery with EC5 Connector
- 1x standard propeller - we recommend the Master Airscrew 10x7 3-Blade Electric Propeller
- 1x reverse propeller - we recommend the Master Airscrew 10x7 3-Blade Electric Propeller (Reverse)
- 3 Cell compatible battery charger - select a minimum 3 cell (3S) charger from our Charger Collection
Nexa ARF models are constructed out of balsa wood and plywood. These are not foam models. The assembly of balsa wood ARF aircraft requires basic model building skills including the installation of servos, ESC, and motor (or gas engine).
Product Specifications:
Model Scale |
1/16 |
Wingspan |
1800mm / 70.8in |
Length |
1200mm / 47.2in |
Weight |
3175.15g / 112oz |
CG (Center of Gravity) |
100-110mm from the leading edge of the wing's root |
Power System |
2x 950Kv Brushless outrunner motors (required) |
Electronic Speed Control |
2x 45A (required) |
Propeller / EDF |
1x 9x7x3 standard and 1x 9x7x3 reverse electric propellers (required) |
Servos |
|
Landing Gear |
Electric retractable (required) |
Required Battery |
TWO 3 Cell 11.1V 5000 mAh LiPo Batteries (required) |
Required Radio |
6+ Channel (required) |
Ailerons |
Yes |
Elevator |
Yes |
Rudder |
Yes |
Flaps |
Yes |
Lights |
No |
Hinge Type |
Nylon |
Material |
Balsa and light plywood |
Skill Level |
Intermediate |
Build Time |
6+ Hours |
Recommended Environment |
Outdoors |
Spare Parts
Product Spare Parts
1 - 26 of 26 results
Q&A
Product questions & answers
NOTE: Questions submitted on this page are answered by customers who have previously purchased this item. If you have a support related question that requires immediate assistance, please visit our Help Center
Support
Product support
Product Manuals:
If you need any additional assistance, please visit the Motion RC Help Center
Customer Reviews
- Reviews
Perfect Maiden
Just flew the maiden in very heavy 15 mph winds down the runway. Plane flew perfectly. Very stable. No trim required at all. Really amazing. Landed with full flaps.
Nexa C-47 DC-3
Es una aeronave extraordinaria muy lindo avión
Great, Fast Service
Really enjoyed working with Motion on several aircraft. Very fast!!
Poor wing dihedral, poor speed controller installation with poor instructions.
Warning
1-st issue is CG. It is impossible to accomplish CG specified by Manual using the two 3 cell 5000mAh LIPOs specified by Motion-RC. You will be super nose heavy. It...read more
instruction manual
there is no any information about or any pictures if you want put any kind of gas/nitro engines and there is no place to put fuel tank ether . thanks
-
